GPU Scheduling mit Nomad

The NVIDIA GPU device plugin exposes NVIDIA GPUs to Nomad so you can run workloads on GPU hardware. Install and configure the plugin on your Nomad clients. Configure job tasks to use GPUs

Deploy a low priority job and a high priority job. Then use preemption to run the higher priority job even when other jobs are running.

Learn how Nomad’s service, batch, system, and system batch job schedulers enable flexible workloads.

Create quotas that you attach to namespaces, and then secure them with ACLs so that you can restrict aggregate resource usage for namespaces.

Nomad’s node pools feature groups clients and segments infrastructure into logical units so that jobs have control over client allocation placement. Review node pool replication in multi-region clusters, built-in node pools, node pool patterns, and enterprise features such as scheduler configuration, node pool governance, and multi-region jobs.

Set up a local Nomad cluster with Vagrant and then use the Nomad Autoscaler to automatically scale an application horizontally in response to increased application load.

IntroductionNomad Autoscaler is a horizontal application and cluster autoscaler for Nomad. Additionally, the enterprise version of Nomad Autoscaler supports Dynamic Application Sizing (DAS). While Nomad Autoscaler and Nomad work hand in hand, the Nomad Autoscaler is built and released separately to Nomad.  Nomad Autoscaler supports several APMs for horizontal scaling; however, currently, Prometheus must be the APM used for Dynamic Application Sizing (DAS).  Many companies, especially those using AWS, use Datadog as the default APM, so we will focus on Datadog and Prometheus.  This article covers how one can configure Nomad Autoscaler to utilize two APMs for horizontal scaling and DAS. Prerequisites (if applicable)Nomad & Consul cluster currently running (Nomad Enterprise (with the Multi-Cluster & Efficiency module) is needed for DAS)Datadog agent installed on each Nomad nodeOverviewAt a high-level the setup process includes:Adding telemetry configuration for nomadDeploy PrometheusDeploy Nomad Autoscaler (Nomad Autoscaler Enterprise is needed for DAS)Deploy load test apps for validation testingThis article utilizes Nomad to deploy both Prometheus and the Nomad Autoscaler as apps within the cluster.  While this is not a hard requirement, it is recommended to deploy Nomad Autoscaler as an app within the cluster. ProceduresAdd telemetry configuration for nomad-  On each of the nomad nodes to be monitored, add the following telemetry stanza to your nomad.hcl file.telemetry {publish_allocation_metrics = truepublish_node_metrics = truedatadog_address = “localhost:8125”collection_interval = “10s”prometheus_metrics = true}- Restart Nomad for the change to take effect. Deploy Prometheus-  Deploy the Prometheus job below --- prometheus.nomad ---job “prometheus” {datacenters = [“dc1″]group “prometheus” {count = 1network {port “prometheus_ui” {static = 9090to = 9090}}task “prometheus” {driver = “docker”config {image = “prom/prometheus:v2.25.0”ports = [“prometheus_ui”]args = [”--config.file=/etc/prometheus/config/prometheus.yml”,”--storage.tsdb.path=/prometheus”,”--web.console.libraries=/usr/share/prometheus/console_libraries”,”--web.console.templates=/usr/share/prometheus/consoles”,]volumes = [“local/config:/etc/prometheus/config”,]}template {data = <<EOH---global:scrape_interval: 1sevaluation_interval: 1sscrape_configs:- job_name: nomadmetrics_path: /v1/metricsparams:format: [‘prometheus’]static_configs:- targets: [‘{{ env “attr.unique.network.ip-address” }}:4646’]- job_name: consulmetrics_path: /v1/agent/metricsparams:format: [‘prometheus’]static_configs:- targets: [‘{{ env “attr.unique.network.ip-address” }}:8500’]EOHchange_mode = “signal”change_signal = “SIGHUP”destination = “local/config/prometheus.yml”}resources {cpu = 500memory = 512}service {name = “prometheus”port = “prometheus_ui”check {type = “http”path = ”/-/healthy”interval = “10s”timeout = “2s”}}}}} Deploy Nomad Autoscaler-  Update the Autoscaler job below with your dd_api_key and dd_app_key (if needed, update the DD site as well)-  Deploy the Autoscaler job --- autoscaler.nomad ---job “autoscaler” {datacenters = [“dc1″]group “autoscaler” {count = 1network {port “http” {}}task “autoscaler” {driver = “docker”config {image = “hashicorp/nomad-autoscaler-enterprise:0.3.6”command = “nomad-autoscaler”ports = [“http”]args = [“agent”,”-config”,“local/autoscaler.hcl”,”-http-bind-address”,“0.0.0.0″,”-http-bind-port”,”${NOMAD_PORT_http}”,]}template {destination = “local/autoscaler.hcl”data = <<EOHnomad {// Use Consul service discovery for the Nomad client IP and Port.address = ”{{ with service “nomad-client” }}{{ with index . 0 }}http://{{.Address}}:{{.Port}}{{ end }}{{ end }}”// Use the slapt operator so the autoscaler monitors scaling policies from// all Nomad namespaces. If you wish to have it only monitor a single// namespace, update this param to match the desired name.namespace = ”*”// If Nomad ALCs are in use, the following line should be uncommented and// updated to include an ACL token.// token = ”″}// Setup the Prometheus APM so that the autoscaler can pull historical and// point-in-time metrics regarding task resource usage.apm “prometheus” {driver = “prometheus”config = {// Use Consul service discovery for the Prometheus IP and Port.address = ”{{ with service “prometheus” }}{{ with index . 0 }}http://{{.Address}}:{{.Port}}{{ end }}{{ end }}”// If you wish to use this example without Consul, you can remove the above// Consul service discovery address section and replace it with the line// below uncommented with an updated endpoint if required.// address = “http://localhost:9090”}}// This block contains configuration options specific to the Dynamic Application// Sizing enterprise feature.dynamic_application_sizing {// Lower the evaluate interval so we can reproduce recommendations after only// 5 minutes, rather than having to wait for 24hrs as is the default.evaluate_after = “5m”}apm “datadog” {config = {dd_api_key = “XXXXXXXXXXXXXXXXXXXXXXXXXXXXX”dd_app_key = “YYYYYYYYYYYYYYYYYYYYYYYYYYYYY”site = “datadoghq.com”}driver = “datadog”}policy_eval {// Disable the horizontal cluster workers. This// helps reduce log noise during the demo.workers = {cluster = 0// horizontal = 0}}policy {default_evaluation_interval = “10s”default_cooldown = “1m”}strategy “fixed-value” {driver = “fixed-value”}strategy “pass-through” {driver = “pass-through”}strategy “target-value” {driver = “target-value”}strategy “threshold” {driver = “threshold”}strategy “app-sizing-avg” {driver = “app-sizing-avg”}strategy “app-sizing-percentile” {driver = “app-sizing-percentile”}EOH}resources {cpu = 512memory = 512}service {name = “autoscaler”port = “http”check {type = “http”path = ”/v1/health”interval = “5s”timeout = “2s”}}}}} Deploy load test apps for validation testing-  There are two jobs used for testing.     -  The first job example.nomad contains two task groups:     1. cache-lb:  This task group is scaled by Dynamic Application Sizing.     2. cache:  This task group is scaled by Horizontal Autoscaling.   - The second job loadtest.nomad is a parametrized job that can be executed at any time, causing load to be generated against the example.nomad tasks. --- example.nomad ---job “example_prom_dd” {datacenters = [“dc1″]group “cache-lb” {count = 1network {port “lb” {}}task “nginx” {driver = “docker”config {image = “nginx”ports = [“lb”]volumes = [# It’s safe to mount this path as a file because it won’t re-render.“local/nginx.conf:/etc/nginx/nginx.conf”,# This path hosts files that will re-render with Consul Template.“local/nginx:/etc/nginx/conf.d”]}# This template overwrites the embedded nginx.conf file so it loads# conf.d/*.conf files outside of the `http` block.template {data = <<EOFuser nginx;worker_processes 1;error_log /var/log/nginx/error.log warn;pid /var/run/nginx.pid;events {worker_connections 1024;}include /etc/nginx/conf.d/*.conf;EOFdestination = “local/nginx.conf”}# This template creates a TCP proxy to Redis.template {data = <<EOFstream {server {listen {{ env “NOMAD_PORT_lb” }};proxy_pass backend;}upstream backend {{{ range service “redis” }}server {{ .Address }}:{{ .Port }};{{ else }}server 127.0.0.1:65535; # force a 502{{ end }}}}EOFdestination = “local/nginx/nginx.conf”change_mode = “signal”change_signal = “SIGHUP”}resources {cpu = 100memory = 20}scaling “cpu” {policy {cooldown = “1m”evaluation_interval = “1m”check “95pct” {source = “prometheus”strategy “app-sizing-percentile” {percentile = “95”}}}}scaling “mem” {policy {cooldown = “1m”evaluation_interval = “1m”check “max” {source = “prometheus”strategy “app-sizing-max” {}}}}}service {name = “redis-lb”port = “lb”address_mode = “host”check {type = “tcp”port = “lb”interval = “10s”timeout = “2s”}}}group “cache” {count = 3scaling {min = 3max = 6enabled = truepolicy {evaluation_interval = “30s”cooldown = “1m”check “CPU_400″ {source = “datadog”query = “nomad.client.allocs.cpu.total_ticks{task:redis}“strategy “target-value” {target = 400}}}}network {port “db” {to = 6379}}task “redis” {driver = “docker”config {image = “redis:6.0”ports = [“db”]}resources {cpu = 500memory = 256}service {name = “redis”port = “db”address_mode = “host”check {type = “tcp”port = “db”interval = “10s”timeout = “2s”}}}}} --- loadtest.nomad ---job “load-test” {datacenters = [“dc1”]type = “batch”parameterized {payload = “optional”meta_optional = [“requests”, “clients”]}group “redis-benchmark” {task “redis-benchmark” {driver = “docker”config {image = “redis:6.0”command = “redis-benchmark”args = [”-h”,”${HOST}”,”-p”,”${PORT}”,”-n”,”${REQUESTS}”,”-c”,”${CLIENTS}”,]}template {destination = “secrets/env.txt”env = truedata = <<EOF{{ with service “redis-lb” }}{{ with index . 0 -}}HOST={{.Address}}PORT={{.Port}}{{- end }}{{ end }}REQUESTS={{ or (env “NOMAD_META_requests”) “100000″ }}CLIENTS={{ or (env “NOMAD_META_clients”) “50″ }}EOF}resources {cpu = 100memory = 128}}}} Nomad Clusters with ACLs EnabledIf you have enabled ACLs in your Nomad cluster, you’ll need to add a token to the autoscaler job before deploying the autoscaler.There are two token types available that can be used for the autoscaler; a management token with all permissions available or a client token which is more constrained when it comes to permissions.If you plan to use a client token with the autoscaler, you’ll need to ensure that it contains the minimum capabilities needed.  The policy file below contains the minimum capabilities needed by the autoscaler. namespace ”*” {policy = “read”capabilities = [“read-job”, “scale-job”, “list-scaling-policies”, “read-scaling-policy”, “read-job-scaling”, “submit-job”]}operator {policy = “read”}node {policy = “read”}plugin {policy = “read”}  Additional Information: Additional Nomad Datadog metrics can be found here.Additional Prometheus Nomad metrics can be found here.Additional documentation for the Nomad Autoscaler can be found here.
